Abso acoustic cushions

Characteristics of Abso Cushions

Composition

• Grey AP cellular foam

• Powder-coated steel hoop

• Cover made of sound-transparent Aeria fabric

Acoustic performance

Equivalent absorption area A (m²) at mid-range frequencies

• 1,250 square: 2.63 m²

• 625 rectangle: 1.51 m²

• 1,800 rectangle: 3.65 m²

• 1,000 round: 1.55 m²

• 1,250 round: 2.18 m²

Durability of the aeria fabric cover

• Run-resistant

• 330 g/m²

• Protection against soiling:

– Hydro/Oleophobic ≥ 5 (AATCC118 and AATCC193)

– Electrostatic properties 7 x 1010 Ω (EN 1149-1)

Reaction to fire classification

Complete product : C-s3, d0

Cleaning

Vacuum cleaning, may be taken apart and refitted, removable covers, machine washable.

Environmental characteristics

• Abso accessories meet the requirements specified in the HQE, LEED and BREEAM (2 points) reference documents and methods, based on:

– their acoustic contribution

– their very low emissions of VOC and formaldehyde

• All Texaa products qualify for French “A+” health labelling and are classed as “conforming” after assessment using the German AgBB protocol

Guarantee 10 years

Special solutions

• Suspended under horizontal cables

• 1,800 oval (1,800 x 1,250 x 95mm)

Fitting

Each Abso Cushion is suspended from the ceiling by means of 4 vertical cables (3 cables for 1,000 round and 1,250 Cushions) made of galvanised steel (diameter 1.5 mm, length 1,000 mm), fitted with M6 threaded end-pieces and adjustable latch-eye hooks. Round Abso Cushions

Diameter: 1000 and 1250 mm

Thickness: 95 mm

Abso Cushions in their square or rectangular with rounded corners versions.

1250 x 625 mm

1250 x 1250 mm

1250 x 1800 mm

Thickness: 95 mm
