Name: THERM+ FS-I
Brand: Raico

Varianti disponibili:

THERM+ FS-I

Architonic ID: 20749011

Use | Application:

- vertical facade

- glass roofs

- suitable for high static requirements

Characteristic:

- Steel facades & glass roofs

- Integrated drainage system in the continuous hat sealing in three levels

- T-Connectors SC and SC-L

Dimension:

- System width 50 or 56 mm

- glass weight up to 1019 kg

- glass thickness from 4 to 64 mm

- profile depth up to 200 mm

Concetto

- Sharp edged profiles due to small radii

- No welding needed for the curtain wall construction

- Integrated screw channel in tube reduces planning, manufacturing and installation costs

- Strip galvanizing of the profiles ex works

- Profiles are all suited for mullion and transom

- Application in the roof possible

Questo prodotto appartiene alla collezione:

Facades and glass roofs
