MINIMAL Look S68 AI²

Name: MINIMAL Look S68 AI²
Brand: ELVIAL

Porte patiodiELVIAL

Visita il prodotto sul sito di ELVIAL

Home

Porte patio

MINIMAL Look S68 AI²

Informazioni su questo prodotto

Architonic ID: 20716869

Overcoming the challenges our natural and cultural environment presents us is our number 1 priority. This system is especially crafted to withstand. With a glazing of 48mm it meets the highest standards of energy efficiency and sound insulation. It is the answer to arduous weather conditions and metropolitan noise.

IDENTITY

System Depth- 68mm

Visible Height– 35mm

Facing Width Middle Mullion (Successive)– 35mm

Facing Width Middle Mullion (Meeting Style)- 109mm

Facing Width Middle Mullion (Fixed T)- -mm

Visible Height (Standard Edition) – 77mm

Max Sash Height- 3.000mm

Max Sash Width- 3.000mm

Max Sash Weight- 400kg

Max Glass thickness – 48mm

Concetto

It started with a concept. That the end product acts as the ideal liaison between your design and its context -the project as a whole, the natural and cultural surroundings, your clients' satisfaction. What is an ideal liaison then? One that is fully effective and dully discreet. Then it became an exercise in implementation. Could the technologies and contrivances that ensure the system's efficiency be accommodated in a diminutive frame? They were. And thus MINIMAL Look was created.
