VIAVAI | BOB - Adjustable light source
- Maison/Plafonniers/
VIAVAI | BOB - Adjustable light source
À propos de ce produit
Architonic ID: 20754074
SKU: 53580-53581
Année de Lancement: 2023
BOB is a LED spot with double joint that allows an inclination of 90° on the horizontal plane and a rotation of 360° around the vertical axis. Aluminum structure and heat sink. Easy replacement of secondary lens. Optics: 30°, 40°, 60°, oval, rectangular, Wallwasher. Different shade LEDs [2700K, 3000K]. BOB sources can be connected to other types of systems [ON-OFF, 0-10V, DALI, DALI 2, CASAMBI].
ON-OFF version
1 x 20W- 48V
ONE BY ONE Dimmable
1 x 20W- 48V
0-10V Dimmable
1 x 20W- 48V
2700K CRI 97- 1800 lm
3000K CRI 97- 1900 lm
To be completed with lenses
Converter included.
IP20 | CE
Kg 0,80
Concept
VIAVAI is a line of 48V linear systems, characterized by innovative solutions unique in the panorama of architectural lighting. We have combined the functionality of low voltage tracks with the practicality of linear lighting profiles in a single product. VIAVAI was developed for both direct and indirect lighting of environments and is also available in the version for wall installation. The light sources are extremely easy to install with a simple gesture, through the use of an innovative snap system.
The VIAVAI MONO track is made of extruded aluminum and finished with epoxy paint in black and white colours. It is cuttable to size. VIAVAI MONO can be installed with direct attachment to the wall or ceiling. It can be suspended or recessed through 4 different fixing systems. Maximum capacity 10A.
The VIAVAI DUO track is made of extruded aluminum and finished with epoxy paint in black and white. It is cuttable to size. VIAVAI DUO is available in the version for wall or suspended installation. Maximum capacity 10A per line.
Ce produit appartient à la collection:
Spécifications du produit
Material
Aluminium, Métal
