1/35

Multiple Pendant

Name: Multiple Pendant
Brand: STICKBULB
SKU: MULTI-PEND

Lámparas de suspensiónporSTICKBULB, Diseñado porRUX.

Inicio

Lámparas de suspensión

Multiple Pendant

Acerca de este producto

Architonic ID: 1425152

SKU: MULTI-PEND

Año de Lanzamiento: 2014

Product Code SKU

Model- Wood Finish- Metal Finish- Color Temp- Voltage- Brightness

Wood Finishes:

Maple- MA

Walnut- WA

Southern Yellow Pine (reclaimed)- SP

Ebonized Oak- EO

Standard Metal Finishes:

Powder Coated White- WH

Powder Coated Slate Grey- SG

Powder Coated Matte Black- MB

Premium Metal Finishes:

Hand Blackened Steel- BL

Polished Nickel- PN

Brushed Brass- BB

Color Temp:

3000K (standard)

2400K, 2700K, 4000K also available

Voltage:

120V 50-60hz- 120

277V 50-60hz- 277

Brightness:

Standard Brightness 12V- SB

High Brightness 24V- HB

Certifications:

UL, CUL

Country of Manufacture:

USA

Fixture Dimensions:

Bulb length: (6) x 2ft, (6) x 3ft, (6) x 4ft, (6) x 5ft, or (6) x 6ft

Canopy Dimensions:

Standard brightness: 12.5” L x 12.5” W x 1.5” H

High brightness (8ft,10ft,12ft only): 18”L x 18”W x 1.5”H

Stem Lengths:

60” length of 3/8” steel stem included, additional stem lengths available upon request

Fixture Weight

10lbs

LED Specs 12V (SB):

Light output & Power Draw:

(3) X 4’ Pendant: 726 lm. Power Draw: 36W

(3) X 6’ Pendant: 1,140 lm. Power Draw: 57W

(3) X 8’ Pendant: 1,554 lm. Power Draw: 78W

(3) X 10’ Pendant: 1,968 lm. Power Draw: 99W

(3) X 12’ Pendant: 2,382 lm. Power Draw: 120W

CRI Rating: 94.222

Lutron driver built-in forward phase dimming driver 100%-1%

Fully dimmable-see list for compatible Lutron Controls

LED Specs 24V (HB):

Light output & Power Draw:

(3) X 4’ Pendant: 1,386 lm. Power Draw: 51 W

(3) X 6’ Pendant: 2,184 lm. Power Draw: 81 W

(3) X 8’ Pendant: 2,976 lm. Power Draw: 111 W

(3) X 10’ Pendant: 3,768 lm. Power Draw: 141 W

(3) X 12’ Pendant: 4,560 lm. Power Draw: 171 W

CRI Rating: 89.5

2 Lutron drivers, built-in forward phase dimming driver 100%-1%

Fully dimmable-see list for compatible Lutron Controls

Concepto

Linear pendants are comprised of a central metal hardware component and two symmetrical bulbs. The overall length of the pendants can range from 2ft, 4ft, 6ft, 8ft, 10ft, or 12ft. A clamping mechanism allows for the leveling of the bulbs. Bulbs can be oriented to provide down-light or uplight. The wooden component is offered in sustainably sourced maple or walnut, reclaimed southern yellow pine, or ebonized oak. Metal hardware is available in powder coated white, slate gray or matte black, hand blackened steel, polished nickel, and brushed brass.

Features:

Handmade in New York City from sustainably sourced materials

Wooden bulb element can be reversed to illuminate up or down

Fully Dimmable

Bulbs available in Standard (SB) or High Brightness (HB)

Materials information:

1. Maple

Sustainably harvested in the Northern territories of the United States, this wood is characterized by its light, homogeneous, and minimal grain.

2. Walnut

Sustainably harvested in Ohio, this wood has a classic, rich, medium-brown chocolate tone.

3. Southern Yellow Pine

Reclaimed from demolished New York City buildings, this wood is remarkable for its reddish hue and rich, old growth grain.

4. Ebonized Oak

Sustainably harvested in the USA, this oak is ebonized to have a dark blackened finish while letting the pronounced texture and grain of the wood shine.
