Concept

The TrendVario 6300 creates more parking spaces in a small area.
The entrance to the TrendVario 6300 is at ground level. Unlike the other models, the system accommodates three vehicles one above the other, and the parking spaces are moved vertically and horizontally: down into the pit or up to the third parking level. The requested parking space is moved into position. This means that they accommodate more cars within the same floor area.
For maximum operating safety, the access level is secured from the entire system by gates. This also protects the vehicles from theft and vandalism. The semi-automatic parking system offers up to 29 parking spaces in total.
You can also enhance your TrendVario 6300 with our premium accessorires.


SPECIFICATION:
For independent parking
10 grids behind each other – up to 29 parking spaces are possible
Building height: 325 cm to 460 cm in 5 cm increments
Pit depth: 175 cm to 240 cm in 5 cm increments
Vehicle dimensions: height 150 cm to 215 cm, length 500 cm  to 520 cm
Usable platform width: 230 cm to 270 cm
Platform load: 2,000 kg per parking space, optionally 2,600 kg or max. 3,000 kg
Horizontal access to all parking levels
Platform coating: StandardGrip, optional AluLongLife or EasyWalk
Operation via SmartChip, SmartPortable or SmartApp

SPECIFICATION GATES:
Standard gates: KLAUS V-Gates, vertical gates, electrically
Electrically sliding gates as an option
Remote control as an option
Gate frame made from extruded aluminium profiles with two vertical centre stay bars for the vertical gate and one vertical centre stay bar for the sliding gate
Standard gating material: perforated aluminium plate
Optional for sliding gates:
Around 50 individual variations are possible in different materials and colours
Glass (laminated safety glass), wood (Nordic spruce), aluminium, steel and many other options available.
Interchangable panels and segments

FIELD OF APPLICATION:
In residential and commercial buildings in large cities
For additional parking spaces in office buildings or residential and commercial buildings
To increase capacity in underground car parks or parking garages, e.g. of hotels
More parking spaces for car dealerships, car rental companies or vintage car collections
Ideal in the case of constructions abutting property lines
