Thor QR111

Name: Thor QR111
Brand: TAL
SKU: 102008-102018-102021-102026

Ceiling lightsbyTAL

Home

Ceiling lights

Thor QR111

About this product

Architonic ID: 1175306

SKU: 102008-102018-102021-102026

Materials and finish:

The housing is made of aluminium with different finishes:

102008 Brushed aluminium + varnish

102018 Textured White powder coating

102026 Textured Black powder coating

102021 Chrome plated

Installation and lamp replacement:

Installation: Base is fixed to the ceiling. Electrical connection is made on that base. The fixture can be snapped on the ceiling base with 2 big leaf springs.

Lamp replacement: the bulb is hold in the lampring by 3 small springs.

Technical data:

Luminaire dimensions: cylinder: diameter 135 X height 175 mm

Weight: 1,8 kg

Accessories:

700703 Frontring 111 Brushed alu

700702 Frontring 111 Chrome

700701 Frontring 111 Textured Black

700700 Frontring 111 Textured White

Electrical data:

Lamp type: QR111

Lamps: 1

Lampholders: G53

Control gear: Integral electronic control gear

Input supply voltage: 230V-50Hz

Connector block: 3x2,5mm²

Glow wire resistance: 960°

IP rating: IP20

Concept

Surface mounted fixture for general & accent lighting applications with powerfull leds.

The cylindrical shaped fixture exist of 2 parts, one part containing the incorporated gear, the other part housing the lampsource.

The fixture is extremely easy to install and after installation no screws remain visible.

The lamp can be oriented over 359° and tilt over 30°. Different finishes are possible. TAL uses a patented technology, PORIFERA for optimized heat dissipation. This technology uses aluminium foam to conduct heat from the leds. TAL uses also it’s own developed PCB for the THOR PASCAL. The result is an elegant led dvice with a long operating lifetime warranty of 5 years.

The THOR PASCAL can be powdercoated in textured white or textured black, leds are available in warm white (3000K) and cool white (6250K) and the beam angle has 2 options: 10° and 40°.

This product belongs to collection:
