NEXTREMA® translucent white (724-5)

Name: NEXTREMA® translucent white (724-5)
Brand: SCHOTT

Decorative glassbySCHOTT

Home

Decorative glass

About this product

Architonic ID: 1489787

Standard format: 1,950 mm x 1,100 mm

Standard thickness: 2 mm – 6 mm (8 mm – 16 mm on request)

Flat cut to size panels:

Width: 50 mm – 1,075 mm

Length: 50 mm – 1,930 mm

Diameter: 20 mm – 1,075 mm

Bent panels: Round, angular bent parts or wok shapes on request

Surface:

- both sides smooth

- one side nubbly

Mechanical treatment:

- Grinding profile: Seamed, C-, U-, V-shape, others on request

- Drilled borehole: Ø 10 mm – Ø 200 mm

- Bevelled edges (width): 5 mm – 20 mm

- others on request

Key properties:

- Visible light reduction in combination with high infrared transmission

- Broadest overall IR transmission window of all NEXTREMA® types

- Excellent chemical resistance & surface hardness

- Transparent for LED light sources

You can find more details in the Material Data Sheet 724-5.

Concept

The NEXTREMA® glass-ceramics material platform combines the benefits of technical glasses with properties of high temperature materials. Due to special production process of NEXTREMA® glass-ceramics six different glass-ceramic material options can be obtained. The economical sheet production process enables the production of large sheets in a thickness range of 2 mm – 8 mm. Especially when costs or limitations in plate sizes of high performance materials like fused silica or technical ceramics have been a restricting factor, NEXTREMA® will be a welcome alternative to generate new product ideas and innovations. The material will even have a lasting impression on designers and end consumers. Six attractive glossy design options and colour impressions will give technical functionality a new look.

NEXTREMA®: Unique combination of properties at a glance:

- Availability of large sheets of up to 1,950 mm x 1,100 mm in thicknesses from 2 mm – 8 mm

- Near-zero coefficient of linear thermal expansion

- 6 unique transmission profiles in visible and infrared range

- Operating temperature up to 950°C

- A high intrinsic mechanical strength of up to 168 MPa

- A thermal shock resistance of up to 820°C

- Excellent chemical resistance
