Portapivot 5730 | Multiple doors
- Home/Internal doors/
Portapivot 5730 | Multiple doors
About this product
Architonic ID: 20183447
Year of Launch: 2021
Technical details
Pivot door system made from high quality anodized aluminium available in 4 decorative finishes, black, silver, bronze and stainless steel. Anodizing is an electrochemical process that converts the metal surface into a decorative, durable, corrosion-resistant finish. The frame can be fitted with any 6 or 8 mm thick tempered glass for endless design purposes.
Specifications
Minimal frame 57 x 30 mm
Available in 4 anodised colours
Compatible with 6 or 8 mm glass
Stealthpivot fitted inside frame
Available with and without door frame
Easy assembly & installation
Dimensions
Minimum height: 1800 mm
Maximum height: 2975 mm
Minimum width: 1500 mm
Maximum width: 10000 mm
Portapivot 5730 kit
Made to measure aluminium frame 57 x 30 mm
Stealthpivot hinge set
Assembly accessories
Stealthpivot
Compact size
Modular axis point
Self-closing technology
-90° 0° +90° open/hold positioning
Configurable swing operation: 180° or 360°
Concept
Our most popular pivot door system, made with a minimal anodised aluminium frame 57 x 30 mm. The frame can be fitted with 6 or 8 mm thick tempered glass.
Portapivot ships its pivot doors as a custom-build kit to interior professionals all around the world. The kit consist of made-to-measure profiles, Stealthpivot hinge and all the necessary assembly and installation accessories. Only glass needs to be sourced at a local supplier.
This product belongs to collection:
Specifications
Material
Glass
