PIXY 23
Share
- Home/Recessed ceiling lights/
PIXY 23
About this product
Architonic ID: 20724058
General data:
Luminare body: aluminum
Mounting: recessed
Impress protection IP: IP20
Operating temperature range: from -20° to +35°
Lifetime L80B10: 100 000h
Electrical data:
Nominal voltage: 230-240V AC
Nominal freguency: 50-60Hz
Protection class: II
Contains light source: yes
Dimming: on-off,DALI, CASAMBI
Optical data:
Optical system: lens
Lenses available: wallwasher
Lighting data:
Light source: LED
Colour rendering index: CRI≥80 (on request: CRI≥90)
Tolerance of luminous flux: SDCM<3
1129lm/ 10W/ 113lm/W/ 4000K/ UGR16
1083lm/ 10W/ 113lm/W/ 3000K/ UGR16
1040lm/ 10W/ 113lm/W/ 2700K/ UGR16
Concept
Effective, clear lighting available in the version of downlight and wall lamp. The luminaire provides even illumination without glare effect- glare factor UGR <18. Two colour temperatures to choose from: warm (3000K) and neutral white (4000K), CRI≥80 (CRI≥90 on request), beam angle 36°.
This product belongs to collection:
Specifications
Category
General lighting
Feature
LED lights
Usage
Office, Retail
Certifications & sustainability
liralighting.pl resources PIXY DEKLARACJE PIXY-23 EN
