Piu Aluminium 5.0
About this product
Architonic ID: 20277082
PIU DOOR SYSTEM : aluminium frame 5.0 and door-leaf made of natural anodized aluminium or several aluminium shades – bright brushed steel, brushed champagne, brushed dark brown or brown black or lacquered in accordance with RAL colour chart
APPLICATION : Inner door
SIZE : Height: from 202 up to 300cm / width: 70, 75, 80, 85, 90, 95 90+, 100 cm
FRAME CONSTRUCTION : Multi-chamber aluminium structure of exceptionally high rigidity; used on masonry walls or on plasterboard walls
OPENING TYPES : 2 types of door frame: opening inwards (type A), opening outwards (type B) – giving the possibility flushed to wall door leads despite the different opening directions; in case of different opening directions the door height is always the same on the side where the door are flushed with wall
DOOR-LEAF CONSTRUCTION : frame of the door-leaf is produced from anodized, brushed or lacquered aluminium in accordance with the RAL colour chart; filled with XPS; covered with prefabricated sheets of materials with a maximum thickness of 5,5-6mm
DOOR-LEAF THICKNESS : 50 mm, high door stability
REBATED : '-- (rebated)
ALUMINIUM STRUCTURES : Natural anodized, brushed in several shades (bright brushed steel, brushed dark brown or brushed black) or lacquered in accordance with RAL colour chart
WALL THICKNESS : 'Min. 100mm
DOOR-LEAF FINISHING MATERIALS : Over 600 finishing materials: acrylic panels, lacquered panels (with polyurethane topcoat in matte with 25-30 glosses, or in gloss with 80-90 glosses, veneered, architectural concrete, Lacobel glass and others
LOCK : Magnetic-mechanical lock; able to adjust for any possible type of locking: handle, master-key, toilet, patent lock or electric door strike
HINGES : Concealed hinges with adjustment in 3 dimensions. The door opens outwards, with an opening range of up to 180º
SEALS : Rubber seals in colours: white, black, brown and grey
ACCESSORIES : Door closer, drop down seal
TECHNICAL DOCUMENTATION : National Technical Assessment ITB nr ITB-KOT-2020/1477 Certificate for hinges according to PN-EN 1935:2003 and Acoustic certificate confirming superior sound insulation properties (35dB)
COUNTRY OF ORIGIN : Poland
MANUFACTURER : PIU Design Sp. z o.o.
Concept
Interior doors and modern walls that are concealed within the overall design scheme are an important feature that significantly influences the first impression we get of any home. PIU ALU doors that may be up to 320 cm tall, mounted flush with the wall and boasting aluminium frames and leaves are a new dimension of internal elegance. Door models 5.0 and 6.5 are all about subtle tones and finish details utilizing wall surface materials that may be up to 8 mm thick. The various colour variants available- brushed black, brushed dark brown and brushed champagne- offer even more elegance and chic. The doors become an integral element of the wall’s design. Our 4.2 and 4.5 models, available with the height of up to 240 cm, rely on more standard solutions. Ceiling-mounted PIU Geometric sliding systems and PIU Baseboard skirts complement the solution that is suitable for any contemporary interior design. PIU ALU Model 4.2 is a modern line of door at standard height of 202cm with aluminium frame 4.2 and wooden leaf in CPL laminate in colours: white, anthracite, black or prepared for wall painting. Raw aluminium frame prepared for painting or finished in black brushed. Model 4.2 is adjusted for PIU aluminium baseboards flushed with wall (PIU S Line).
This product belongs to collection:
Aluminium, Metal
