LivingSculpture 3D module system

Modular light installations of the third kind – with the Philips LivingSculpture 3D module system, users can concentrate fully on the design of their three dimensional light installations.The technical know-how and controls are both taken care of by the module system.

Planning a light installation is challenging, especially when it involves a spacial light construction. Up till now, making such projects effective needed extensive planning and a high level of expertise. The LivingSculpture 3D module system is the Philips Lumiblade solution that allows the user to concentrate fully on the design.Technical know- how can be left to the module system, which is composed of separate tiles and linking rods. And with linking rods available in a range of different lengths, complex three-dimensional surfaces can be created quickly and easily. No matter what

the project, no end of tiles can be fixed together to create a spell-binding, three-dimensional light installation.

LivingSculpture 3D module system

Module dimensions: 32.4 x 32.4 cm (12.7 x 12.7 in) (1pcs/package, seemless combinable)

OLED head dimensions incl. frame: 7.8 x 7.8 cm (3 x 3 in)

Max. rod plug-in positions per module: 16 Max. OLEDs per module: 16 OLEDs

Length of rods available in inter vals of 2.5 cm (0.9 in): 2.5 cm (0.9 in) – 40 cm (15.75 in) (Rods according to ordered installation) Online configurator at www.lumiblade.com

Rod shapes: straight Finishing module: chrome

Weight: ~3.5 kg/module (incl. full equipment with OLEDs, rods, etc.)

Electrical Specifications

Power in: 100 V – 240 V, AC, 50/60 Hz, 60 W Power out: 24 V, DC (SELV)

Content Management

Data input: DMX via ArtNet

Hardware: Apple MacBook Pro*, ENTTEC Data Gate Software: WHITEvoid LivingSculpture DMX-Control

Or up to 64 modules via DMX-Player Hardware: Philips Color Kinetics IPlayer V3 Software: Philips Color Kinetics ColorPlay 3

Option: Apple iPad* for live animation

Installation

4 screws/module in base plate to the surface

OLED Specs

Outer dimensions: 7.8 x 7.8 cm (3 x 3 in)

Color temperature: ~3,000K Max. luminance per OLED: ~2,000 cd/m2 (nits)
