Gouged Effect Sycamore with shade 990

Standard wood panel, ready-for-use, made of a substrate bonded on one side with an Oberflex® real wood laminate and counterbalanced on the other side..

JOINTING

bookmatched or random-matched (depends of the references)

FINISHES

satin, relief, matte, brushed

SUBSTRATES

standard particle board E1 (CTBS)

standard MDF E1

SUBSTRATE THICKNESS

16 mm (0.47”)• total thickness: 18 mm (0.70”)

19 mm (0.62”)• total thickness: 21 mm (0.82”)

DIMENSIONS

unfinished edges

particle board :

304 x 123 cm (4’ x 10’)

250 x 123 cm (4’ x 8’)

MDF :

304 x 120 cm (4’ x 10’)

250 x 120 cm (4’ x 8’)

COUNTERBALANCING

Panober can be bonded with 3 different kinds of counterbalancing

A/A

2 visible sides• same wood species.

A/C

1 visible side• 1 counterbalancing side (second grade Oberflex).

A/P

1 visible side• 1 counterbalancing side (white granitelike decor).

FIRE RATINGS:

particle board : M2 (n° 9153-00 of SNPE)

MDF : M3 (n° 11682-04 of SME)
