Matric F3 IP54 | System 55mm Recessed Frame
- Home/Recessed ceiling lights/
Matric F3 IP54 | System 55mm Recessed Frame
About this product
Architonic ID: 1498436
Recessed mounted LED luminaire for installation in ceiling cut-outs openings. Direct only light distribution. Light channel with surrounding frame made of aluminium profile. Optic width 55mm. Surface natural anodised or white, graphite, black, champagne or copper coated. Further surface options see Lightnet-Surface-Collection or RAL of your choice. Satin opal diffuser for general lighting with maximum transmittance and homogeneous lighting. Driver integrated into luminaire housing, optionally switchable or dimmable (DALI, Touch-Dim, Casambi). Colour temperature 2200K, 2700K, 3000K, 3500K, 4000K, 6500K or Tunable White (2700-6500K). Binning≤ MacAdam 3. Colour rendering CRI>80, CRI>90 or Full Spectrum. Mounting brackets included. Ingress protection IP54.
Concept
Designer luminaire for the office
Matric is the most variable light line system, which, in addition to a comprehensive standard range, can always be manufactured to millimeter precision according to specifications. Based on three light channel widths (system 40mm, 55mm and 81mm), it offers a variety of different profile cross-sections for mounting on the wall and on and in concrete-plasterboard and modular ceilings.
The diverse lighting technology options include high-performance lens reflector optics, wallwashers, microprism optics and opal diffusers. The illumination is always perfect, regardless of whether straight light lines or complex structures with angles and corners are realized. Almost all profiles can also be combined with 3-phase or 48V tracks and spotlights.
This product belongs to collection:
