Liquid Line TX | System 40mm Table Asymmetric
- Home/Table lights/
Liquid Line TX | System 40mm Table Asymmetric
About this product
Architonic ID: 20704559
LED surface-mounted luminaire with 3-phase track adapter. Direct only light distribution. Luminaire body with smooth bends made of aluminium, crafted in one piece with no visible seams at the ends. Surface white, silver, graphite, black or champagne coated. Further surface options see Lightnet- Surface-Collection or RAL of your choice. Precision lenses with louvre for wide uniform symmetrical light distribution with low glare (UGR<19) especially for workplaces. Louvre available in various colour finishes. Optional satin opal diffuser for general lighting with maximum transmittance and homogeneous lighting. Driver integrated into luminaire housing, optionally switchable or dimmable (DALI). Colour temperature 2200K, 2700, 3000K, 3500K, 4000K or 6500K. Binning≤ MacAdam 3. Colour rendering CRI>80, CRI>90 or Full Spectrum. 3-phase adapter options, EUTRAC or GLOBAL.
Concept
One with the architecture
The Liquid Line product family adapts perfectly to the shapes of the architecture and forms a form-fitting unit with the building. In-house production makes its flexibility unique on the market, enabling smooth transitions and merging with the premises- for a unique architectural experience.
The Origin
For years, architecture was characterised by cubism- functionalism and clear lines were in the foreground. Through new building technologies, the forms of architecture became increasingly organic and expressive, characterised by flowing lines and new combinations. This architectural development in combination with LED technology, which makes almost any form technically feasible, enabled us to think much more freely in terms of design and forms. This was the birth of the Liquid Line. Lightnet was the first manufacturer on the market with a flexible light line for flowing shapes and to this day we are the only supplier who can implement all radii horizontally and vertically.
Uniquely flexible
Highly flexible system suitable for millimetre-precise cutting to size as well as individual solutions.
Individually configurable
Any combination of circular elements with all linear and curved elements of the Liquid Line 3D family is possible.
Versatile areas of application
The diversity of the Liquid Line is also reflected in the areas of application: from offices to shops, shopping centres, hotels, public buildings, lobbies and churches to clinics and educational institutions, there are no limits.
Limitless possibilities
The Liquid Line's recipe for success: it offers a broad portfolio of standard modules and at the same time can be produced in any conceivable shape- for perfect customisation. Thus, the Liquid Line is not only flexible on the horizontal plane, modules with a customised vertical bend are also possible.
Lighting features
Unlimited possibilities also apply to the technical lighting features: light colours, colour rendition, opal diffusers and microprismatic optics for glare-free use in offices are freely configurable. Direct and indirect light can be switched separately, and a wide variety of colours and surfaces promote perfect architectural adaptation.
