Name: Kubus II - T
Brand: Strähle

Soundproofing room-in-room systemsbySträhle

Visit product on Strähle website

Home

Soundproofing room-in-room systems

Kubus II - T

About this product

Architonic ID: 1489400

Year of Launch: 2016

Design: Modular room-in-room system with double glazing in wood / glass visual

Dimensions: Lenght: 2.684 / 3.934 / 5.184 mm; Width: 2.750 mm; Height: 2.530 mm

Wall thickness: 100 mm

Glazing: 6 and 8 mm toughened glass

Door: Solid door 64 mm or all-glass door 10 mm (Rw,P 37 / 32 dB)

Sound insulation: Norm sound level difference when installed Dn,T,w= 36 dB, (corresponds to a sound insulation value R’ w = 42 dB)

Acoustic: acoustic absorbers integrated in solid wall and integrated in ceiling

Control: Touch-Display für Steuerung Lüftung und Licht (opt. Kühlung)

Ventilation: integrated into ceiling, Steplessly adjustable comfort mode up to 150 m³/h

Cooling: Cooling convector integrated into the sideboard: Comfort mode up to approx. 700 watts or self-contained electrical cooling element as a plug & play solution

Concept

Retreat, conference room, think tank: Strähle room-in-room systems create new rooms in open spaces. Kubus II-T is the new, highly soundproofed wood-glass Kubus based on the successful Kubus II design.

The high-quality and stylish optics of the System T with its wood mullion/transom construction is achieved using the contrast between the wooden surfaces and the glazing. The flush-fit glazing and the narrow visible width of the laminated wood mullion substructure contribute to the elegant design. By using wood as a CO2-neutral building material, this Kubus variant supports sustainable architectural concepts. The comfort features of the Kubus II-T system, starting from soundproofing and room acoustics to ventilation and cooling, are the same as those of the Kubus II.
