Porto EPL43Q (71)

Lever sets for standard doors acc. to DIN EN 1906, category of use 3

Clip rose

with 7mm lugs

thread in bushing

nylon floating bearing

sprung loaded inner plate with attached lever

Heavy duty bolt through M4 fixings

8mm offset drilled spindle

Mounting version: surface mounting only

Door thickness: 40-50mm, depending on door version (rebated or flush)

Options:

OS – without escutcheon

BB – supplied with lever key escutcheons

PZ – supplied with euro profile escutcheons

BAD – supplied with bathroom turn/release set

Attention: Before mounting check length of profile cylinder

Finish: satin stainless steel (finish code 71)

Karcher article no.:

EPLQXX OS 71 – without escutcheon

EPLQXX BB0 71 – supplied with lever key escutcheons

EPLQXX PZ0 71 – supplied with euro profile escutcheons

EPLQXX BAD 71 – supplied with bathroom turn/release set

Lever models XX

ED17 (Crete XL), ED18 (Rhodos XL), ED19 (Jersey), ED22 (Elba), ED25 (Malta), ED26 (Sylt), ED27 (Crete), ED28 (Rhodos), ED29(Cyprus), ED30 (Corsica), ED31 (Tasmania), ED34(Rio Steel), ED35 (Lignano), ED44 (Oslo), ED45 (Madeira), ED47 (Portland), ED48 (OREGON), ED64 (Ontario), ED79 (Stockholm), ED84 (Futura), ED85 (Miami)
