Chicago R220 (56)

Lever sets for standard doors

Lever version R220 Chicago

by KARCHER DESIGN

Solid 3-piece fixing rose

and escutcheons squared, 52 x 10 mm,

with 7mm lugs and nylon floating bearing,

sprung loaded inner plate with attached lever

Heavy duty bolt through M4 fixings

8mm offset drilled spindle,

diameter of handle: 18 x 28 mm

standard door thickness: 39- 47 mm

Options:

OS – without escutcheon

BB – supplied with lever key escutcheons

PZ – supplied with euro profile escutcheons

BAD – supplied with bathroom turn/release set

Finish: chrome/satin chrome (finish code 56)

Karcher article no.:

R220 OS 56 – without escutcheon

R220 BB0 56 – supplied with lever key escutcheons

R220 PZ0 56 – supplied with euro profile escutcheons

R220 BAD 56 – supplied with bathroom turn/release set
