K310610

TOTAL WEIGHT 685 ± 65 g/m2

WIDTH Min. 1,37 m

THICKNESS 1.10 ± 0.16 mm

SUBSTRATE Polyester

TENSILE STRENGTH warp >= 392 N / fill >= 245 N

ELONGATION warp >= 50 % / weft >=96 %

TEAR STRENGTH warp >= 30 N / weft >= 30 N

STITCHING STRENGTH warp >= 39 N / weft >= 26 N

ADHESION warp >= 29 N / weft >= Full

CROCKING RESISTANCE —

COLD CRACK RESISTANCE dry: good / wet: good

FIRE RETARDANCY:

FMVSS 302

Boston Fire IX-1

IMO A 652 (16) 8.2-8.3

Fed. St. 191 A M 5903

FAR 25.853 b(4) Ap. F Part. 1 (a) (1) (ii)

UNE 23.727-90 1R = M2NFP 92503 / M2

BS EN 1021-1 y 2

DIN EN 1021-1 y 2

DIN 4102 B2

DIN 53438 / K1

DIN 75200

ÖNORM B 3825 / Grupo 1

ÖNORM B 3800 Teil 1

SURFACE PROTECTION Permablok
