Facades | EF50

EF50 is a new generation 50mm curtain walling system. It provides:

- stick or bonded glazed (widely known as structurally glazed) options;

- accommodation to typical infill thicknesses (single, double glazing and panels);

- integration with projected constructions, such as external shading;

- material optimal solutions with exceptionally high testing performances;

- wide range of project profiles for custom applications;

- incorporation of ETEM systems as infills."

System basic width: 50mm

Min./max. system basic depth: 64mm / 249mm

Glazing infill range: 8 ÷ 36 mm

Max. weight: 500kg

Inertia mullions (Ix: wind load): up to 1.411cm4

Inertia transoms (Ix: wind load): up to 926cm4

Inertia transoms (Iy: glass load): up to 60cm4

Uf ≥ 1,02 W/(m2K)
