IQ lavatory faucet A10, with IR-Sensor, with mixing, with drain assembly - battery

IQ lavatory faucet A10, with IR-Sensor, with temperature-mixing, with drain assembly, chrome- battery Touch-free, electronically controlled lavatory faucet:- Modular single-piece design without separate installation box, sturdy metal housing, chromed- Dual infrared sensors (with automatic setting feature), microprocessor- Reliable solenoid valve (minimal level of water pressure surge) and economic aerator- Hot and cold water supply connection with flexible high-pressure hose- Check valves and built-in filters- Temperature adjustable or fixable (vandal-proof construction)- Scald protection adjustable- Temporary-off (cleaning) and continuous water flow time (filling of basin) activated by Click-plus- Continuous water flow time and hygienic rinse water flow time adjustable with function key- Follow-up time and sensor sensitivity adjustable with function key- 12,24 or 48-hour hygienic rinse activatable with function key- Installation similar to conventional single-lever faucet- Compatible service monitor: control of stored operational data, settings and control functions- With drain assembly Click-plus: Protruding function key Click-plus (continuous-on, temporary-off) Click: Recessed function key- without additional functions Battery: 6 V Lithium 2 CR5- commercial; life time up to 4 years Operating pressure: 0,3-10 bar Flow rate: Approx. 6 l/min. (3 bar) Max. water temperature.: 80 °C Aerator: Economy aerator, cascade (self-cleaning) Flexible hose: 350 mm Angle valve connection: G 3/8 Built-in filter: 0,5 mm mesh size Sensor-sensivity: Automatic self-adapting sensor technology Follow-up time: 1 sec. pre-set (adjustable with function key 0-10 sec.) Continuous water flow and hygienic rinse time: 2 min. pre-set (adjustable with function key 0,5-20 min.) Temporary-off: 2 min. (fixed) Engineering standards: DIN EN 200; Noise class I; P-IX 9576 / IA

100.101.11 battery

100.111.11 mains operation exposed

100.117.11 VARIOconnect
