Areaplan Work

The office environment is constantly evolving to adapt to the functional, ergonomic and technological changes that involve it. The Areaplan Work programme has therefore been developed by taking all these needs into account, in order to set up office spaces without setting limits to operational requirements.

Areaplan Work is a flexible partition wall system consisting of modular elements available in 4 lengths: 600- 800- 1000- 1200 mm and 3 heights: 1060- 1380- 1700 mm. The depth is 67 mm.

The structural components of the system are made of a metal frame with a section of 40x20 mm equipped on the vertical uprights with rack and pinion slots used for hooking the panels and the various accessories such as reception shelves, hanging furniture, shelves.

The frame is equipped with adjustable feet for perfect levelling on the floor; on the two internal vertical sides the frame is provided with holes for the connection between modules and for the passag,e both horizontally and vertically, of the electrification. The electrical connections can be conveyed to the worktop through a special socket holder that can be inspected by means of a tilting window located on the frame's infill panels.

C section metal crosspieces complete the frame and have the function of strengthening and supporting glazed panels and modules. The anchorage between the blind and glazed finishing panels is made with a hook that has to be fixed to the panels and to a bracket which has to be fitted to the frame.

The system includes vertical finishing elements made of aluminium that have to be fixed to the frame with screws. There are also 2, 3 or 4-way corner connecting elements to create articulated compositions and guarantee greater flexibility.

The partition panels are made of 12 mm thick chipboard. The wide choice of colours and finishes, ranging from melamine, lacquered to fabric coverings, offers greater creative freedom to design your own work area and regain concentration thanks to the acoustic comfort.

The glazed modules consist of two metal frames mounted opposite each other that are assembled to the structure with hooks. A 5 m thick transparent glass is inserted in each frame. The modules can be completely blind, glazed or mixed.

Areaplan Work can be easily equipped with work and service tops, satisfying the need forindividual and shared social activities.
