ah! Sliding | ah!NM Minimalist Window

Without any state of the art precedent when it comes to minimal windows, ah! Noble Metals will feature materials such as stainless and carbon steel and architectural bronze, allowing numerous architectural solutions. With the same ah!geometry, ah! noble metals presents slim high performing profiles with increased mechanical strength. The sliding system was developed to offer not only excellent acoustic and thermal insulation but according to the inherent characteristics of the different metals it can also be appropriate to the roughest environments or the most sophisticated designs.

Metals available: Stainless steel, carbon and corten steel, architectural bronze.

Finishes available: Blasted, brushed, polished & aged.

glazing up to:

max double glazing area: 19m²

max triple glazing area: 6m²

glass thickness: 38mm

main dimensions up to:

max. leaf height: 6000mm

max. leaf width: 6000mm

max. weight / glass pannel: 2.000kg

vertical profile: 20mm

performance up to:

thermal coefficient: Uw = 0.75W/m².K (Ug = 0.5W/m².K)

air tightness: Class 4

wind resistance: Class C5

water tightness: Class E900

sound insulation: 41dB

security: RC2

achievements: fire rated EI15

sliding system:

fixed, sliding, invisible frame, pocket, corner, curved, skylight, sash, pivot, tilt & turn
