Mitica Sliding

Name: Mitica Sliding
Brand: ADL

Internal doorsbyADL, designed byMassimo Luca.

Home

Internal doors

Mitica Sliding

About this product

Architonic ID: 20180002

Year of Launch: 2005

Types of opening systems:

sliding door

sliding door with drag

pocket door

swing

pivot

folding

Aluminium

- All the profiles are in extruded aluminium alloy EN AW 6O-6O, temper designation T6.

- Anodic oxidation in compliance with regulations in force.

Glass panes

- The glass panes are always safe: tempered / laminated tempered.

- Shatterproof glass in compliance with regulations in force.

- 6 mm glass pane.

Profiles

- Can be covered in real wood essences.

Sliding system

Telescopic track. The system permits the track to be perfectly level, guaranteeing that the doors always slide fluidly.

Sliding door carriage with 4 nylon coated bearings. Maximum load 120 kg per carriage. Automatic breaking mechanism for the opening and closing of the leaf, standard on all models. The system for installing the leaf onto the carriages is completely concealed. Telescopic door stop profile with travel of 12 mm (for ceiling-mounted track).

Folding system

The complete opening of the pair of leaves is guaranteed by the concealed hinge with 3-axis adjustment.

Concept

The Mitica collection is characterised by its meticulous aesthetics, given to the aluminium profile that houses the central glass pane, and to the geometry of the door frame which is made with 18 mm wide uprights and 36 mm wide crosspieces. Thanks to the high construction technology and the historicity of the product, Mitica doors are available with all types of opening systems.
