Prisma

Prisma is a collection formed by two columns and a light beacon for public areas, characterised by its thin prismatic geometry. It easily blends into the landscape, with three optional materials for the column: concrete, wood and steel. The lamp holder has an extruded polycarbonate diffuser that deflects the light flow, giving it an attractive beacon-like effect in addition to its main lighting function.

Prisma was created as a technological review of a classic model from 1991, originally supplied only in concrete and wood. Beacon-like effect with a minimum UHF coefficient of 2.48 %. IP65 seal, IP67 LED equipment, IK09 protection against impacts and protection against transient overvoltages.

in three heights and with a common cross section of 16 x 16 cm: Prisma 420, Prisma 320 and Prisma 100, with three material options: grey reinforced concrete with an etched, water-repellent finish; autoclave treated Scandinavian pine wood with fungicide protection and zinc-coated steel with a Cor-ten steel effect paint finish. Lamp holder with a cast aluminium base and top cover and an extruded clear polycarbonate diffuser with an internal microgroove. LED 700 mA 38 V module for Prisma 420 and Prisma 320 and LED 500 mA 29 V module for Prisma 100.

All three column models share a stainless steel anchor plate measuring 22 x 22 cm which is anchored below the paving to the concrete foundation with the recommended generic dimensions. Must be unloaded and handled with slings.
