Wall / ceiling luminaire 3563/6860/... by BEGA

Wall / ceiling luminaires

Protection class IP 44
Die cast aluminium and stainless steel
Satin matt three-ply opal glass
Colour: graphite

• incandescent lamps D 45 40 W
• incandescent lamps A 60 60 · 75 · 100 W
• fluorescent lamps TC-D 13 · 18 · 26 W

Incandescent lamps
3563: Light brick 1 D 45, 40 W, Lumen 400; A=80, B=190, C=90 mm
3668: Light brick 1 A 60, 60 W, Lumen 710; A=100, B=210, C=90 mm
4661: Light brick 1 A 60, 75 W, Lumen 940; A=120, B=250, C=100 mm
3266: Light brick 2 A 60, 60 W, Lumen 1420; A=140, B=300, C=110 mm
3363: Light brick 2 A 60, 100 W, Lumen 2720; A=210, B=370, C=110 mm

Fluorescent lamps
3648: Light brick 1 TC-D, 13 W, Lumen 900; A=100, B=210, C=90 mm
3372: Light brick 1 TC-D, 18 W, Lumen 1200; A=120, B=250, C=100 mm
3370: Light brick 1 TC-D, 26 W, Lumen1800; A=140, B=300, C=110 mm
3374: Light brick 2 TC-D, 18 W, Lumen 2400; A=210, B=370, C=110 mm


Incandescent lamps
6860: Light brick 1 A 60, 75 W, Lumen 940; A=100, B=200, C=120 mm
6960: Light brick 1 A 60, 100 W, Lumen 1360; A=120, B=250, C=130 mm
6965: Light brick 2 A 60, 60 W, Lumen 1420; A=140, B=300, C=140 mm

Fluorescent lamps
6971: Light brick 1 TC-D, 18 W, Lumen 1200; A=120, B=250, C=130 mm
