Recessed ceiling luminaires 8381/8382/.. by Glashütte Limburg

Recessed ceiling luminaires

Crystal glass with light-diffusing texture, inside white
Anodized reflector of pure aluminium
Die-cast aluminium luminaire housing and frame
Surface finish of the frame optionally
• white aluminium enamel RAL 9006
• white enamel RAL 9010
With 2 cable entries for through-wiring
The required ballasts are fitted.
When preparing the recessed opening, it may be practical to use an installation housing. Installation housings made of aluminium and glass-fibre reinforced plastic with 4 cable entries are given in the table.
Installation housings are accessories and must be ordered separately.
Protection class IP 65

• fluorescent lamps TC-TELI · electronic ballast

White aluminium
8381: 1 TC-TELI, 18 W, Lumen 1200; A=190, B=255, C=175, D=100 mm
8382: 2 TC-TELI, 26 W, Lumen 3600; A=250, B=355, C=230, D=115 mm
8383: 2 TC-TELI, 32 · 42 W, Lumen 6400; A=300, B=405, C=280, D=120 mm
Dimensions installation housing on request

White
8378: 1 TC-TELI, 18 W, Lumen 1200; A=190, B=255, C=175, D=100 mm
8379: 2 TC-TELI, 26 W, Lumen 3600; A=250, B=355, C=230, D=115 mm
8380: 2 TC-TELI, 32 · 42 W, Lumen 6400; A=300, B=405, C=280, D=120 mm
Dimensions installation housing on request
