GROHE Ondus | Grohe AG

Designer GROHE Inhouse Designteam
Year 2008
Architonic id 1085735

GROHE Ondus® stands alone as a bold aesthetic statement. Daring to evolve the geometric boundaries of minimalism, its advanced curvature gives the design its effortless minimalist appearance. Radiating simplicity and purity, its seductive form creates an instant emotional lure, subtly provoking interaction. The fluid curved spout directs the water in a natural way respecting its fluidity and elegance – leaning toward the user, it allows the water to cascade in an optimal position. GROHE Ondus® – the perfect balance of technology, quality and design.

Reflective finishes optimise the flow of natural light within an interior. Materials and surfaces are chosen for their balance and purity – creating a restful atmosphere and heightening our sensitivity. Minimalism is softened, resulting in soulful spaces that stimulate interaction and encourage relaxation.

Performance Art is the balance of aspirational design, innovative technology and unsurpassed quality. To achieve perfection, these three attributes must work together in harmony. We are committed to deliver unique experiences, to innovate and inspire and to exceed expectations. This collection functions as beautifully as it looks.


The products are available in the following colours:
Velvet Black = KS0
Moon White = LS0
Titanium = BS0
Chrome = 000

  1. grohe-ag-grohe-ondus-3-hole-bidet-mixer
    ceramic headparts 1/2", 90°
    ball-joint mousseur
    pressure-proof, flexible connection hoses
    between spout and side valves
    Push-open waste set 1 1/4"
    click escutcheon
    GROHE Ondus 3-hole bidet mixer
    Year 2008
    ID 24 031 KS0
    Architonic id 1085700


  2. grohe-ag-grohe-ondus-talentofill-inlet-pop-up-and-waste-system
    set for final installation consisting of:
    escutcheon
    supply part
    waste plug
    fixing set

    in combination with Talentofill 28 990/28 991
    in combination with Talentofill 28996/28997
    GROHE StarLight® chrome finish
    GROHE Ondus Talentofill Inlet-, pop-up and waste-system
    Year 2008
    ID 19 952 KS0
    Architonic id 1085832


  3. grohe-ag-grohe-ondus-side-shower-massage
    2 spray patterns:
    Normal, Massage
    SpeedClean anti-lime system
    ball-joint
    minimum flow rate 4 l/min.
    GROHE StarLight® chrome finish
    GROHE Ondus Side shower Massage
    Year 2008
    ID 27 067 KS0
    Architonic id 1085833


  4. grohe-ag-grohe-ondus-metal-hose
    1500 mm
    1/2" x 1/2"
    Longlife
    strengthened model
    tensile strength 750N
    pressure resistance 10 bar
    GROHE StarLight® chrome finish
    GROHE Ondus Metal hose
    Year 2008
    ID 28 143 KS0
    Architonic id 1085834


  5. grohe-ag-grohe-ondus-wall-plate
    for dual flush or start & stop actuation
    for pneumatic discharge valve AV1
    vertical and horizontal installation
    156 x 197 mm
    made of ABS
    GROHE Ondus Wall plate
    Year 2008
    ID 38 766 KS0
    Architonic id 1085835


  6. grohe-ag-grohe-ondus-digital-operating-panel
    for bath and shower
    wall mounted
    advanced touch operating panel with backlit icons
    integrated digital display and intuitive menu navigation
    2 personalized pre set programs
    diverter: head-/side-/hand shower/bath spout
    GROHE SafeStop at 38°C
    programmable, automatic safety shut-off (with default setting)
    extra low voltage supply 6 V DC
    CE approved
    type of protection:
    operating panel IP 69K
    for use with:
    concealed thermostat unit 36 067
    installation kit 36 068
    GROHE Ondus Digital operating panel
    Year 2008
    ID 36 050 KS0
    Architonic id 1085735


  7. grohe-ag-grohe-ondus-digital-basin-mixer
    with display
    single hole installation
    advanced touch operating panel with backlit icons
    integrated digital display and intuitive menu navigation
    function unit
    integrated temperature sensor
    plug power supply 230 V AC / 6 V DC
    integrated battery back up
    6V lithium-battery, type CR-P2
    battery status indicator on display
    GROHE Ondus flow straightener
    Push-open waste set 1 1/4"
    flexible connection hoses
    digital flow limiter
    programmable, automatic safety shut-off (with default setting)
    CE approved
    type of protection:
    faucet IP 66
    plug power supply IP 40
    battery unit IP 66
    operating panel IP 69K
    upgrade option with pre set panel 45 983
    GROHE Ondus Digital basin mixer
    Year 2008
    ID 36 060 KS0
    Architonic id 1085739


  8. grohe-ag-grohe-ondus-digital-basin-mixer
    with display and pre set panel
    single hole installation
    advanced touch operating panel with backlit icons
    integrated digital display and intuitive menu navigation
    wireless sensual touch pre set panel with long life 3V lithium battery CR-2032
    2 personalized pre set programs
    3 personalized pre set programs for face rinse,
    hand wash and teeth brushing
    function unit
    integrated temperature sensor
    plug power supply 230 V AC / 6 V DC
    integrated battery back up
    6V lithium-battery, type CR-P2
    battery status indicator on display
    GROHE Ondus flow straightener
    Push-open waste set 1 1/4"
    flexible connection hoses
    digital flow limiter
    programmable, automatic safety shut-off (with default setting)
    CE approved
    type of protection:
    faucet IP 66
    plug power supply IP 40
    battery unit IP 66
    operating panel IP 69K
    pre set panel IP 57
    to be used with 36 078
    GROHE Ondus Digital basin mixer
    Year 2008
    ID 36 061 KS0
    Architonic id 1085740


  9. grohe-ag-grohe-ondus-digital-bath-mixer
    free standing
    floor-mounted
    total height from finished floor 1040mm
    consisting of:
    advanced touch operating panel with backlit icons
    integrated digital display and
    intuitive menu navigation
    2 personalized pre set programs
    diverter: hand shower/bath spout and additional head or side shower
    GROHE SafeStop at 38°C
    integrated temperature sensor
    bath spout with GROHE Ondus flow straightener
    GROHE Ondus hand shower 27 184
    shower hose 1500 mm (28 143)
    protected against backflow
    digital flow limiter
    programmable, automatic safety shut-off (with default setting)
    extra low voltage supply 6 V DC
    incl. cable protection and cables
    CE approved
    type of protection:
    operating panel IP 69K
    for use with:
    concealed thermostat unit 36 067
    installation kit 36 069
    GROHE Ondus Digital bath mixer
    Year 2008
    ID 36 048 KS0
    Architonic id 1085732


  10. grohe-ag-grohe-ondus-5-hole-bath-combination
    consisting of:
    bath inlet
    GROHE Ondus flow straightener
    handles
    ceramic headparts 1/2", 90°
    GROHE Ondus hand shower 27 184
    metal shower hose 2000 mm
    diverter bath/shower
    click escutcheon
    flow limiter 20 l/min.
    GROHE Ondus 5-hole bath combination
    Year 2008
    ID 31 047 KS0
    Architonic id 1085712


  11. grohe-ag-grohe-ondus-single-lever-basin-mixer
    single hole installation
    GROHE SilkMove® 28 mm ceramic cartridge
    GROHE Ondus flow straightener
    Push-open waste set 1 1/4"
    pressure-proof, flexible connection hoses
    flow limiter 6 l/min
    GROHE Ondus Single-lever basin mixer
    Year 2008
    ID 32 589 KS0
    Architonic id 1085713


  12. grohe-ag-grohe-ondus-single-lever-bidet-mixer
    single hole installation
    GROHE SilkMove® 28 mm ceramic cartridge
    Push-open waste set 1 1/4"
    ball-joint mousseur
    pressure-proof, flexible connection hoses
    GROHE Ondus Single-lever bidet mixer
    Year 2008
    ID 32 695 KS0
    Architonic id 1085715


  13. grohe-ag-grohe-ondus-thermostat-shower-mixer
    wall mounted
    GROHE EcoJoyTM technology for less water and perfect flow
    GROHE CoolTouch® safety housing
    GROHE TurboStat® compact cartridge with wax thermoelement
    integrated mixed water shut off
    Carbodur ceramic headpart 1/2", 180°
    volume handle with GROHE EcoButton
    (economy button with individually adjustable economy stop)
    GROHE SafeStop at 38°C
    shower bottom outlet 1/2"
    dirt strainers
    covered S-unions
    protected against backflow
    GROHE Ondus Thermostat shower mixer
    Year 2008
    ID 34 258 KS0
    Architonic id 1085718


  14. grohe-ag-grohe-ondus-digital-basin-mixer
    single hole installation
    wireless sensual touch operating panel
    with long life 3V lithium battery CR-2032
    function unit
    integrated temperature sensor
    plug power supply 230 V AC / 6 V DC
    integrated battery back up
    6V lithium-battery, type CR-P2
    GROHE Ondus flow straightener
    Push-open waste set 1 1/4"
    flexible connection hoses
    digital flow limiter
    programmable, automatic safety shut-off (with default setting)
    CE approved
    type of protection:
    faucet IP 66
    plug power supply IP 40
    battery unit IP 66
    operating panel IP 57
    GROHE Ondus Digital basin mixer
    Year 2008
    ID 36 043 KS0
    Architonic id 1085719


  15. grohe-ag-grohe-ondus-rainshower-jumbo-shower-head
    Ø 400 mm
    brass
    normal (wide) spray starting at 0.5 bar flow pressure
    SpeedClean anti-lime system
    ball joint with turning angle 20° ± 20°
    connection thread 1/2"
    This head shower should only be used in conjunction with shower arm 28 982 or 28 497
    suitable for instantaneous heater
    GROHE Ondus Rainshower Jumbo shower head
    Year 2008
    ID 27 193 KS0
    Architonic id 1085708


  16. grohe-ag-grohe-ondus-rainshower-shower-head
    brass
    Ø 210 mm
    normal (wide) spray starting at 0.5 bar flow pressure
    SpeedClean anti-lime system
    ball joint with turning angle 20° ± 20°
    connection thread 1/2"
    This head shower should only be used in conjunction with shower arm 28 497, 28 576, 28 361 or 28 982!
    suitable for instantaneous heater
    GROHE Ondus Rainshower shower head
    Year 2008
    ID 27 287 KS0
    Architonic id 1085709


  17. grohe-ag-grohe-ondus-digital-basin-mixer
    for free-standing basins
    single hole installation
    wireless sensual touch operating panel
    with long life 3V lithium battery CR-2032
    function unit
    integrated temperature sensor
    plug power supply 230 V AC / 6 V DC
    integrated battery back up
    6V lithium-battery, type CR-P2
    GROHE Ondus flow straightener
    Push-open waste set 1 1/4"
    flexible connection hoses
    flow limiter 6 l/min
    programmable, automatic safety shut-off (with default setting)
    CE approved
    type of protection:
    faucet IP 66
    plug power supply IP 40
    battery unit IP 66
    operating panel IP 57
    GROHE Ondus Digital basin mixer
    Year 2008
    ID 36 044 KS0
    Architonic id 1085720


  18. grohe-ag-grohe-ondus-bath-spout
    wall mounted
    GROHE Ondus flow straightener
    projection 178 mm
    flow limiter 20 l/min.
    GROHE Ondus Bath spout
    Year 2008
    ID 13 210 KS0
    Architonic id 1085695


  19. grohe-ag-grohe-ondus-thermostat-bath-mixer
    set for final installation for Rapido 35 500
    without concealed body
    temperature scale handle with
    GROHE SafeStop at 38°C
    Aquadimmer with multiple function
    metal handles
    metal escutcheon
    escutcheon- and shaft-sealings
    covered fixing
    GROHE Ondus Thermostat bath mixer
    Year 2008
    ID 19 442 KS0
    Architonic id 1085696


  20. grohe-ag-grohe-ondus-concealed-valve-exposed-part
    set for final installation for 29 032
    installation depth infinitely adjustable 43 - 91 mm
    bayonet union escutcheon
    GROHE Ondus Concealed valve exposed part
    Year 2008
    ID 19 444 KS0
    Architonic id 1085697


  21. grohe-ag-grohe-ondus-three-hole-basin-mixer
    ceramic headparts 1/2" - 90°
    GROHE Ondus flow straightener
    Push-open waste set 1 1/4"
    pressure-proof, flexible connection hoses
    between spout and side valves click escutcheon
    flow limiter 6 l/min
    GROHE Ondus Three-hole basin mixer
    Year 2008
    ID 20 149 KS0
    Architonic id 1085698


  22. grohe-ag-grohe-ondus-three-hole-basin-mixer
    wall mounted
    set for final installation for 29 025
    ceramic headparts 1/2" - 90°
    GROHE Ondus flow straightener
    Push-open waste set 1 1/4"
    projection 178 mm
    centre distance 200 mm
    flow limiter 6 l/min
    click escutcheon
    only for use with concealed body 29 025
    GROHE Ondus Three-hole basin mixer
    Year 2008
    ID 20 152 KS0
    Architonic id 1085699


  23. grohe-ag-grohe-ondus-hand-shower
    normal spray
    SpeedClean anti-lime system
    GROHE Ondus Hand shower
    Year 2008
    ID 27 184 KS0
    Architonic id 1085702


  24. grohe-ag-grohe-ondus-hand-shower-holder
    wall mounted
    not adjustable
    GROHE Ondus Hand shower holder
    Year 2008
    ID 27 188 KS0
    Architonic id 1085703


  25. grohe-ag-grohe-ondus-wall-union
    male thread
    protected against backflow
    GROHE Ondus Wall union
    Year 2008
    ID 27 190 KS0
    Architonic id 1085704


  26. grohe-ag-grohe-ondus-digital-aquafountain
    wall mounted
    advanced touch operating panel with backlit icons
    integrated digital display and intuitive menu navigation
    2 personalized pre set programs
    Head shower with 2 spray patterns: wide spray / laminar curtain spray
    GROHE Ondus hand shower 27 184
    diverter: head shower (wide or laminar curtain spray) or hand shower
    GROHE SafeStop at 38°C
    integrated temperature sensor
    programmable, automatic safety shut-off (with default setting)
    extra low voltage supply 6 V DC
    incl. cable protection and cables
    CE approved
    type of protection:
    operating panel IP 69K
    for use with:
    concealed thermostat unit 36 067
    installation kit 36 076
    GROHE Ondus Digital Aquafountain
    Year 2008
    ID 27 191 KS0
    Architonic id 1085706


  27. grohe-ag-grohe-ondus-digital-bath-spout
    single hole installation
    wireless sensual touch operating panel
    with long life 3V lithium battery CR-2032
    integrated temperature sensor
    function unit
    plug power supply 230 V AC / 6 V DC
    integrated battery back up
    6V lithium-battery, type CR-P2
    GROHE Ondus flow straightener
    digital flow limiter
    programmable, automatic safety shut-off (with default setting)
    CE approved
    type of protection:
    faucet IP 66
    operating panel IP 57
    for use with: concealed body 36 065
    GROHE Ondus Digital bath spout
    Year 2008
    ID 36 049 KS0
    Architonic id 1085733


  28. grohe-ag-grohe-ondus-digital-2-hole-bath-combination
    set for final installation consisting of:
    advanced touch operating panel with backlit icons
    integrated digital display and
    intuitive menu navigation
    2 personalized pre set programs
    diverter: hand shower/bath spout and additional head or side shower
    GROHE SafeStop at 38°C
    integrated temperature sensor
    bath spout with GROHE Ondus flow straightener
    GROHE Ondus hand shower 27 184
    metal shower hose 2000 mm
    protected against backflow
    digital flow limiter
    programmable, automatic safety shut-off (with default setting)
    extra low voltage supply 6 V DC
    incl. cable protection and cables
    CE approved
    type of protection:
    operating panel IP 69K
    for use with:
    concealed thermostat unit 36 067
    installation kit 36 068
    GROHE Ondus Digital 2-hole bath combination
    Year 2008
    ID 36 047 KS0
    Architonic id 1085731


  29. grohe-ag-grohe-ondus-digital-bidet-mixer
    single hole installation
    wireless sensual touch operating panel
    with long life 3V lithium battery CR-2032
    function unit
    integrated temperature sensor
    plug power supply 230 V AC / 6 V DC
    integrated battery back up
    6V lithium-battery, type CR-P2
    ball-joint mousseur
    Push-open waste set 1 1/4"
    flexible connection hoses
    programmable, automatic safety shut-off (with default setting)
    CE approved
    type of protection:
    faucet IP 66
    plug power supply IP 40
    battery unit IP 66
    operating panel IP 57
    GROHE Ondus Digital bidet mixer
    Year 2008
    ID 36 046 KS0
    Architonic id 1085727


  30. grohe-ag-grohe-ondus-digital-basin-mixer
    with display
    wall mounted
    advanced touch operating panel with
    backlit icons
    integrated digital display and
    intuitive menu navigation
    battery status indicator on display
    integrated temperature sensor
    GROHE Ondus flow straightener
    Push-open waste set 1 1/4"
    digital flow limiter
    programmable, automatic safety shut-off (with default setting)
    CE approved
    type of protection:
    operating panel IP 69K
    for use with:
    concealed body 36 065
    installation kit 36 074
    upgrade option with pre set panel 45 983
    GROHE Ondus Digital basin mixer
    Year 2008
    ID 36 045 KS0
    Architonic id 1085722


  31. grohe-ag-grohe-ondus-champagne-bucket
    free standing
    GROHE Ondus Champagne bucket
    Year 2008
    ID 40 388 000
    Architonic id 1088334


  32. grohe-ag-grohe-ondus-robe-holder
    free standing
    GROHE Ondus Robe holder
    Year 2008
    ID 40 387 000
    Architonic id 1088335


  33. grohe-ag-grohe-ondus-glass
    satin glass
    for combination with holder 40 376
    GROHE Ondus Glass
    Year 2008
    ID 40 390 000
    Architonic id 1088336


  34. grohe-ag-grohe-ondus-soap-dish
    satin glass
    for combination with holder 40 376
    GROHE Ondus Soap dish
    Year 2008
    ID 40 391 000
    Architonic id 1088338


  35. grohe-ag-grohe-ondus-soap-dispenser
    satin glass
    content 125ml
    for combination with holder 40 376
    GROHE Ondus Soap dispenser
    Year 2008
    ID 40 389 000
    Architonic id 1088339


  36. grohe-ag-grohe-ondus-holder
    for glass, soap dish or soap dispenser
    without glass, soap dish or soap dispenser
    GROHE Ondus Holder
    Year 2008
    ID 40 376 000
    Architonic id 1088340


  37. grohe-ag-grohe-ondus-towel-rail
    Towel rail
    GROHE Ondus Towel rail
    Year 2008
    ID 40 381 000
    Architonic id 1088341


  38. grohe-ag-grohe-ondus-toilet-brush-set
    wall model
    satin glass
    GROHE Ondus Toilet brush set
    Year 2008
    ID 40 380 000
    Architonic id 1088342


  39. grohe-ag-grohe-ondus-towel-ring
    Towel ring
    GROHE Ondus Towel ring
    Year 2008
    ID 40 379 000
    Architonic id 1088343


  40. grohe-ag-grohe-ondus-toilet-paper-holder
    without cover
    GROHE Ondus Toilet paper holder
    Year 2008
    ID 40 377 000
    Architonic id 1088344


  41. grohe-ag-grohe-ondus-robe-hook
    Robe hook
    GROHE Ondus Robe hook
    Year 2008
    ID 40 378 000
    Architonic id 1088345
