Cento of Hess

Cento Hess

Designer Klaus Begasse
Architonic id 1052460

Request catalogue PDF catalogues Offer Price request Contact Distribution partners Homepage CAD-files

Send page Print page Save page QR-Code Gallery

Share on Facebook

Tweet on Twitter

Submit on StumbleUpon

Stumble

Surface mounted ground luminaire

TC-D 10/13W SKI
Light fitting of aluminium
Cover of polyacrylic glass (PMMA) with frosted surface
Elec.equip.: 1xG24d-1, TC-D 10/13W
Ingress protection IP54, protection rating I
Without lamp
Bollard of aluminium tube ø 160 mm, total height 280 mm
Embedded base with 2 openings for cable entry
Colour: Glimmer DB 701
More

Cento 280
ID 12.71730.0

Architonic id 1052460
Surface mounted Wall-/Ceiling luminaire

TC-D 10/13W SKI
Housing of cast aluminium
Polyacrylic glass (PMMA) cover with frosted surface
Elec. equipment: 1xG24d-1, TC-D 10/13W
Ingress protection IP54, protection rating I
Without lamp
Colour: Glimmer DB 701
Connection: 3 x 2,5 mm² inside the light
Weight: approx.4,5 kgs
More

Cento
ID 12.11700.0

Architonic id 1053191
Illuminating bollard

T 26 16W SKI - MIT ERDSTÜCK
Light fitting of aluminium
Cover of polyacrylic glass (PMMA) with frosted surface
Elec.equip.: 1xG13, T26 16W
Ingress protection IP54, protection rating I
Without lamp
Total height 900 mm, ø 160 mm
Embedded base with 2 openings for cable entry
Colour: Glimmer DB 701
Connection: 3 x 2,5 mm² terminal inside the bollard
More

Cento
ID 12.71700.0

Architonic id 1052632
Illuminating bollard

TC-D 10/13W SKI
Light fitting of aluminium
Cover of polyacrylic glass (PMMA) with frosted surface
Elec.equip.: 1xG24d-1, TC-D 10/13W
Ingress protection IP54, protection rating I
Without lamp
Bollard of aluminium tube ø 160 mm, total height 500 mm
With flange plate ø 220 mm
Colour: Glimmer DB 701
Connection: 3 x 2,5 mm² terminal in the base of the bollard
More

Cento 500
ID 12.71710.0

Architonic id 1052633
Illuminating bollard

TC-D 10/13W SKI
Light fitting of aluminium
Cover of polyacrylic glass (PMMA) with frosted surface
Elec.equip.: 1xG24d-1, TC-D 10/13W
Ingress protection IP54, protection rating I
Without lamp
Bollard of aluminium tube ø 160 mm, total height 900 mm
With flange plate ø 220 mm
Colour: Glimmer DB 701
Connection: 3 x 2,5 mm² terminal in the base of the bollard
Weight: approx.10 kgs
More

Cento 900
ID 12.71710.0

Architonic id 1052634
