Plus
modul R 256 LED
Année de projet
2009
Numéro ID d'Architonic 1078719
Please be aware that this product is not longer in production. (A3)
-
Ultra-flat 10 mm thick LED.next ceiling-mounted luminaire for direct mounting. As an option, also available with mounting bracket for cavity (Halox-0 or Ø 68 mm hole). Mainly downlighting (approx. 95 %), wide beam. Additional ceiling lighting and very even, almost ceiling-height illumination of walls from secondary light. External Nimbus converter required. The converter can be integrated in a suspended ceiling or an in-ceiling junction box. The luminaire can be directly fastened to this in-ceiling junction box.
3 W LED.next = 10 W halogen
Ø 110 × 10 mm (direct mounting) Ø 110 × 47 mm (cavity mounting)
LED.next technology, 3 W power supply, 24 V DC
95% downwards
IP20
Plus
modul R 9 LED
Numéro ID d'Architonic 1106802
-
LED.next ceiling luminaire with plastic surface-mounted housing, brilliant white with integrated converter for connection to (existing) 230-volt-ceiling outlet or, in the version without integrated converter, to the (existing) 24-volt-ceiling outlet. The surface-mounted housing serves as space for connections. Mainly (approx. 95%) downlighting, wide beam. Additional ceiling lighting and very even, almost ceiling height illumination of walls from secondary light.
3 W LED.next = 10 W halogen
Ø 110 × 57 mm (with converter) Ø 110 × 37 mm (without converter)
LED.next technology, 4 W / 230 V AC (with converter) 3 W / 24 V DC (without converter)
95% downwards
IP20
Plus
modul R 9 surface LED
Numéro ID d'Architonic 1106803
-
Ultra-flat 10 mm thick spray water resistant ceiling LED.next luminaire for outdoors and damp rooms. Direct mounting. As an option, also available with mounting bracket for cavity (Halox-0 or Ø 68 mm hole). Beam mainly direct (approx. 95 %), wide beam. Additional ceiling lighting and very even, almost ceiling-height illumination of walls from secondary light. External Nimbus converter required. The converter can be integrated in a suspended ceiling or an in-ceiling junction box. The luminaire can be directly fastened to this in-ceiling junction box.
3 W LED.next = 10 W halogen
Dimensions
Ø 110 x 10 mm
Ø 110 x 47 mm ( cavity mounting )
Light technology LED.next technology,
3 W power supply, 24 V DC
Luminous flux approx. 155 lm
Colour temperature 3000 K
Light distribution 95 % direct beam
Degree of protection IP44
Plus
modul R 9 aqua LED
Numéro ID d'Architonic 1158582
-
Ultra-flat 10 mm thick ceiling-mounted LED.next luminaire for fitting directly to the ceiling. As an option, also available with mounting bracket for cavity (Halox-0 or Ø 68 mm hole). Mainly (approx. 95 %) downlighting, wide beam. Additional ceiling lighting and very even, almost ceiling-height illumination of walls from secondary light. External Nimbus converter required. The converter can be integrated in a suspended ceiling or an in-ceiling junction box. The luminaire can be directly fastened to this in-ceiling junction box.
9 W LED.next = 50 W Halogen
Ø 135 × 10 mm (direct mounting) Ø 135 × 49 mm (cavity mounting)
LED.next technology, 9 W power supply, 24 V DC
95% downwards
IP20
Plus
modul R 36 LED
Numéro ID d'Architonic 1106804
-
LED.next ceiling luminaire with plastic surface-mounted housing, brilliant white with integrated converter for connection to the (existing) 230-volt-ceiling outlets or, in the version without integrated converter, to the (existing) 24-volt-ceiling outlets. The surface-mounted housing serves as space for connections. Beam mainly direct (approx. 95 %), wide beam. Additional ceiling lighting and very even, almost ceiling height illumination of walls from secondary light.
9 W LED.next = 50 W Halogen
Dimensions
Ø 135 × 52 mm (with converter)
Ø 135 × 37 mm (without converter)
Light technology
LED.next technology, 11 W power supply,
230 V AC (with converter)
LED.next technology, 9 W power supply,
24 V DC (without converter)
Luminous flux approx. 546 lm
Colour temperature 3000 K
Light distribution 95 % direct beam
Degree of protection IP20
Plus
modul R 36 surface LED
Numéro ID d'Architonic 1158583
-
Ultra flat 10 mm thin spray water resistant ceiling LED.next luminaire for outdoors and damp rooms. Direct mounting. As an option, also available with mounting bracket for cavity (HaloX-O or Ø 68 mm hole). Beam mainly direct (approx. 95 %), wide beam. Additional ceiling lighting and very even, almost ceiling-height illumination of walls from secondary light. External Nimbus converter required. The converter can be integrated in a suspended ceiling or an in-ceiling junction box. The luminaire can be directly fastened to this in-ceiling junction box.
9 W LED.next = 50 W Halogen
Dimensions
Ø 135 x 10 mm (direct mounting)
Ø 135 × 49 mm (cavity mounting)
Light technology LED.next technology,
9 W power supply, 24 V DC
Luminous flux approx. 546 lm
Colour temperature 3000 K
Light distribution 95 % direct beam
Degree of protection IP44
Plus
modul R 36 aqua LED
Numéro ID d'Architonic 1158584
-
LED.next ceiling luminaire, continuously tiltable up to approx. 90° and rotatable up to approx. 350°. Beam mainly direct (approx. 95 %), wide beam. Version with narrow beam by means of integrated lens technology. With white rotatable and tiltable unit. The wall illumination effect by means of secondary lighting is largely maintained. External Nimbus converter required. The converter can be integrated in a suspended ceiling or an in-ceiling mounting box.
9 W LED.next = 50 W Halogen
Dimensions
Ø 135 × 58,5 mm
Light technology LED.next technology,
9 W power supply, 24 V DC
Luminous flux approx. 547 lm (narrow)
Colour temperature 3000 K
Light distribution 95 % direct beam
Degree of protection IP20
Plus
modul R 36 tt LED
Numéro ID d'Architonic 1158585
-
LED.next ceiling luminaire, continuously tiltable up to approx. 90° and rotatable up to approx. 350°. Mainly downlighting (approx. 95 %), wide beam. Version with narrow beam by means of integrated lens technology. With white rotatable and tiltable unit. The wall illumination effect by means of secondary lighting is largely maintained. Version with integrated converter for connection to 230-volt ceiling outlets.
9 W LED.next = 50 W Halogen
Dimensions
Ø 135 × 31 mm (without converter)
Ø 135 × 58 mm (with converter)
Light technology
LED.next technology, 9 W power supply,
24 V DC (without converter)
LED.next technology, 11 W power supply,
230 V AC (with converter)
Luminous flux approx. 546 lm (wide)
approx. 547 lm (narrow)
Colour temperature 3000 K
Light distribution 95 % direct beam
Degree of protection IP20
Plus
modul R 36 tt surface LED
Numéro ID d'Architonic 1158587
-
Ultra-flat 10 mm thick ceiling-mounted LED.next luminaire for fitting directly to the ceiling. As an option, also available with mounting bracket for cavity (Halox-0 or Ø 68 mm hole). Mainly (approx. 95%) downlighting, wide beam. Additional ceiling lighting and very even, almost ceiling-height illumination of walls from secondary light. External Nimbus converter required. The converter can be integrated in a suspended ceiling or an in-ceiling junction box. The luminaire can be directly fastened to this in-ceiling junction box.
11 W LED.next = 70 W halogen
Ø 200 × 10 mm (direct mounting) Ø 200 × 49 mm (cavity mounting)
LED.next technology, 11 W / 24 V DC
95% downwards
IP20
Plus
modul R 49 LED
Numéro ID d'Architonic 1106805
-
LED.next ceiling luminaire with plastic surface-mounted housing, brilliant white with integrated converter for connection to (existing) 230-volt-ceiling outlet or, in the version without integrated converter, to the (existing) 24-volt-ceiling outlet. The surface-mounted housing serves as space for connections. Mainly (approx. 95%) downlighting, wide beam. Additional ceiling lighting and very even, almost ceiling height illumination of walls from secondary light.
11 W LED.next = 70 W halogen
Ø 200 × 47 mm (with converter) Ø 200 × 37 mm (without converter)
LED.next technology, 13,4 W / 230 V AC (with converter) 11 W / 24 V DC (without converter)
95% downwards
IP20
Plus
modul R 49 surface LED
Numéro ID d'Architonic 1106806
-
Ultra-flat 10 mm thick spray water resistant ceiling LED.next luminaire for outdoors and damp rooms. Direct mounting. As an option, also available with mounting bracket for cavity (HaloX-O or Ø 68 mm hole). Beam mainly direct (approx. 95 %), wide beam. Additional ceiling lighting and very even, almost ceiling-height illumination of walls from secondary light. External Nimbus converter required. The converter can be integrated in a suspended ceiling or an in-ceiling junction box. The luminaire can be directly fastened to this in-ceiling junction box.
11 W LED.next = 70 W Halogen
Dimensions
Ø 200 x 10 mm (direct mounting)
Ø 200 × 49 mm (cavity mounting)
Light technology LED.next technology,
11 W power supply, 24 V DC
Luminous flux approx. 813 lm
Colour temperature 3000 K
Light distribution 95 % direct beam
Degree of protection IP44
Plus
modul R 49 aqua LED
Numéro ID d'Architonic 1158588
-
Ultra flat 10 mm thick ceiling-mounted LED.next luminaire for direct mounting to the ceiling. As an option, also available with mounting bracket for cavity (Halox-O or Ø 68mm hole). Mainly (approx. 98%) downlighting, wide beam. Additional ceiling lighting and very even, almost ceiling-height illumination of walls from secondary light. External Nimbus converter required. The converter can be integrated in a suspended ceiling or an in-ceiling junction box. The luminaire can be directly fastened to this in-ceiling junction box.
19 W LED.next = 100 W halogen
Ø 280 × 10 mm (direct mounting) Ø 280 × 49 mm (cavity mounting)
LED.next technology, 19 W / 24 V DC
98% downwards
IP20
Plus
modul R 64 LED
Numéro ID d'Architonic 1106807
-
LED.next ceiling luminaire with plastic surface-mounted housing, brilliant white with integrated converter for connection to (existing) 230-volt-ceiling outlets or, in the version without integrated converter, to the (existing) 24-volt-ceiling outlets. The surface-mounted housing serves as space for connections. Beam mainly direct (approx. 98 %), wide beam. Additional ceiling lighting and very even, almost ceiling height illumination of walls from secondary light.
16 W LED.next = 100 W Halogen
Dimensions
Ø 273 × 37 mm ( with or without converter )
Light technology LED.next technology,
20 W power supply, 230 V AC (with converter)
LED.next technology, 16 W power supply,
24 V DC (without converter)
Luminous flux approx. 1020 lm
Colour temperature 3000 K
Light distribution 98 % direct beam
Degree of protection IP20
Plus
modul R 64 surface LED
Numéro ID d'Architonic 1158590
-
Ultra-flat 10 mm thick spray water resistant ceiling-mounted LED.next luminaire for outdoors and damp rooms. Direct mounting. As an option, also available with mounting bracket for cavity (HaloX-O or Ø 68 mm hole). Beam mainly direct (approx. 98 %), wide beam. Additional ceiling lighting and very even, almost ceiling-height illumination of walls from secondary light. External Nimbus converter required. The converter can be integrated in a suspended ceiling or an in-ceiling junction box. The luminaire can be directly fastened to this in-ceiling junction box.
16 W LED.next = 100 W Halogen
Dimensions
Ø 273 × 10 mm (direct mounting)
Ø 273 × 49 mm (cavity mounting)
Light technology LED.next technology,
16 W power supply, 24 V DC
Luminous flux approx. 1020 lm
Colour temperature 3000 K
Light distribution 98 % direct beam
Degree of protection IP44
Plus
modul R 64 aqua LED
Numéro ID d'Architonic 1158592
-
LED.next ceiling luminaire with plastic surface-mounted housing, brilliant white with integrated converter for connection to (existing) 230-volt-ceiling outlet or, in the version without integrated converter, to the (existing) 24-volt-ceiling outlet. The surface-mounted housing serves as space for connections. Mainly (approx. 98%) downlighting, wide beam. Additional ceiling lighting and very even, almost ceiling height illumination of walls from secondary light.
21 W LED.next = 100 W Halogen
Ø 323 × 47 mm (with converter)Ø 323 × 37 mm (without converter)
LED.next technology, 27 W / 230 V AC (with converter) 21 W / 24 V DC (without converter)
98% downwards
IP20
Plus
modul R 100 surface LED
Numéro ID d'Architonic 1106813
-
Ultra flat 10 mm thick ceiling-mounted LED.next luminaire for direct mounting to the ceiling. As an option, also available with mounting bracket for cavity (Halox-O or Ø 68mm hole). Mainly (approx. 98%) downlighting, wide beam. Additional ceiling lighting and very even, almost ceiling-height illumination of walls from secondary light. External Nimbus converter required. The converter can be integrated in a suspended ceiling or an in-ceiling junction box. The luminaire can be directly fastened to this in-ceiling junction box.
21 W LED.next = 100 W halogen
Ø 323 × 10 mm (direct mounting) Ø 323 × 93 mm (cavity mounting)
LED.next technology, 21 W / 24 V DC
98% downwards
IP20
Plus
modul R 100 LED
Numéro ID d'Architonic 1106800
-
Round LED.next ceiling luminaire for suspended mounting. Satin-frost acrylic diffusor plate, Ø 650mm, 8mm thick, both sides matt with 129 dimples for direct light and reduction glare. Mainly downlight (approx. 99%), wide beam. Aluminium supports and canopy, white. Suitable for workspace lighting in accordance with DIN EN 12464-1. Includes stainless steel suspension cables, adjustable from 150–1500 mm.
38,5 W LED.next = 200 W halogen
Ø 650 x 150–1500 mm
LED.next technology, 38,5 W / 230 V AC
99% downwards
IP20
Plus
modul R 120 xl LED
Numéro ID d'Architonic 1106798
-
Round LED.next ceiling luminaire for suspended mounting. Satinfrost acrylic diffusor plate, Ø 650 mm, 8 mm thick, both sides matt with with 129 dimples for directing light and suppressing glare. Light distribution 55 % direct beam, 45 % indirect beam, wide beam. Aluminium supports and canopy, white. Suitable for workspace lighting in accordance with DIN EN 12464-1. Includes stainless steel suspension cables, adjustable from 150–1500 mm.
72 W LED.next = 200 W halogen
Dimensions
Ø 650 x 150-1500 mm
Light technology LED.next technology,
72 W power supply, 230 V AC
Luminous flux approx. 3960 lm
Colour temperature 3000 K
Light distribution
55 % direct beam, 45 % indirect beam
Degree of protection IP20
Plus
modul R 120 xl LED with additional indirect light
Numéro ID d'Architonic 1158595
-
Ultra flat 10 mm thick ceiling-mounted LED.next luminaire for direct or cavity mounting. As an option, also available with mounting bracket for cavity (Halox-O or Ø 68mm hole). Mainly (approx. 98%) downlighting, wide beam. Additional ceiling lighting and very even, almost ceiling-height illumination of walls from secondary light. External Nimbus converter required. The converter can be integrated in a suspended ceiling.
40 W LED.next = 200 W halogen
Ø 388 × 10 mm (direct mounting) Ø 388 × 93 mm (cavity mounting)
LED.next technology, 40 W / 24 V DC
98% downwards
IP20
Plus
modul R 144 LED
Numéro ID d'Architonic 1106808
-
LED.next ceiling luminaire with plastic surface-mounted housing, brilliant white with integrated converter for connection to (existing) 230-volt-ceiling outlets or, in the version without integrated converter, to the (existing) 24-volt-ceiling outlets. The surface-mounted housing serves as space for connections. Beam mainly direct (approx. 98 %), wide beam. Additional ceiling lighting and very even, almost ceiling height illumination of walls from secondary light.
30 W LED.next = 200 W Halogen
Dimensions
Ø 388 × 52 mm (with converter)
Ø 388 × 32 mm (without converter)
Light technology LED.next technology,
34 W power supply, 230 V AC (with converter)
Luminous flux approx. 2502 lm
Colour temperature 3000 K
Light distribution 98 % direct beam
Degree of protection IP20
Plus
modul R 144 surface LED
Numéro ID d'Architonic 1158594
-
Round LED.next ceiling luminaire for suspended mounting. Satin-frost acrylic diffusor plate, Ø 900mm, 8mm thick, both sides matt with 277 dimples for direct light and reduction glare. Mainly downlight (approx. 99%), wide beam. Aluminium supports and canopy, white. Suitable for workspace lighting in accordance with DIN EN 12464-1. Includes stainless steel suspension cables, adjustable from 150–1500mm.
80 W LED.next = 400 W halogen
Ø 900 x 150-1500 mm
LED.next technology, 80 W / 230 V AC
99% downwards
IP20
Plus
modul R 256 xl LED
Numéro ID d'Architonic 1106799
-
Round LED.next ceiling luminaire for suspended mounting. Satin-frost acrylic diffusor plate, Ø 1120mm, 8mm thick, both sides matt with 429 dimples for direct light and reduction glare. Mainly downlight (approx. 99%), wide beam. Aluminium supports and canopy, white. Suitable for workspace lighting in accordance with DIN EN 12464-1. Includes stainless steel suspension cables, adjustable from 150–1500mm.
126 W LED.next = 600 W halogen
Ø 1120 x 150-1500 mm
Plus
modul R 460 xl LED
Année de projet
2009
Numéro ID d'Architonic 1078720
-
Round LED.next ceiling luminaire for suspended mounting. Satinfrost acrylic diffusor plate, Ø 1120 mm, 8 mm thick, both sides matt with 429 dimples for directing light and suppressing glare. Light distribution 80 % direct beam, 20 % indirect beam, wide beam. Aluminium supports and canopy, white. Suitable for workspace lighting in accordance with DIN EN 12464-1. Includes stainless steel suspension cables, adjustable from 150–1500 mm.
150 W LED.next = 600 W Halogen
Dimensions
Ø 1120 x 150-1500 mm
Light technology LED.next technology,
150 W power supply, 230 V AC
Luminous flux approx. 9020 lm
Colour temperature 3000 K
Light distribution
80 % direct beam, 20 % indirect beam
Degree of protection IP20
Plus
modul R 460 xl LED with additional indirect light
Année de projet
2009
Numéro ID d'Architonic 1158596
