In-ground floodlights 8800/8782/... de BEGA

In-ground floodlights

Pressure load 4000 kg
Installation depth 170 · 185 mm
Light output from one, two or four sectors or unshielded with guard
Protection class IP 67
High-strength die cast aluminium and stainless steel
Optical lens made of silica glass
8782 · 8783 White crystal glass with texture
1.5 m connecting cable H07RN-F3G 1.5
1.2 m PVC protective tube for underground cable up to connecting sleeve
Colour: graphite

• low voltage tungsten halogen lamps, QT 12-ax 50 W
• discharge lamps HIT-CE 35 W, Lampholder G 12
• high voltage lamps 40 W – E 27
• fluorescent lamps TC-D 13 W

unshielded with guard
8782: 1 high volt. lamp, 40 W, Lumen 240; A=220, B=255, C=185, D=60 mm
8783: 1 TC-D, 13 W, Lumen 900; A=220, B=255, C=185, D=60 mm
