FlatBoxLED fbl-12

fbl ‒ folding bending light ‒

This series impresses with its unique design language. Precise edges with no visible joints are the result of a specially developed and protected folding technique, which makes it possible to manufacture the housing from just one single panel. Non-positively connected to the integrated heat sink, it enlarges the cooling surface and thus becomes a thermally relevant component of the luminaire. Thanks to professional lens technology, the characteristic, rectangular light emission surface produces a rotationally symmetrical beam pattern. recessed, surface-mounted and track-mounted models are available, which are particularly effective in moderate room heights and show their form to best advantage. The design of the fbl product family is completed by powerful floor lamps with original fbl spotlight design.

colors:

white matt (RAL 9016)

black matt (RAL 9005)

edelstahlähnlich (eloxalähnlich C31)

anodized medium bronze C33 mawa

individual RAL colors on request

Lens unit:

spot 12°

medium 30°

flood 45°

Controller:

schaltbar

DALI dimmbar

Casambi Bluetooth dimmbar

Control gear:

inklusive

LED Module:

15 W

L90(9k) > 63.500h (IES LM-80 / TM-21)

Light color:

3000 K

2700 K

4000 K

Color rendering index:

Ra > 95 (typ. 97)

Dimensions:

163 × 26 × 50 mm (L × B × H)
