Metal Ceiling Wide Panel von Hunter Douglas
The panels can simply be fixed on the carrier by hanging one side of the panel on the prongs of the carrier and pressing the other side with an upward movement. Integrated locking clips onto the carrier can be used. This system is also available for exterior use.
Closed ceiling type in 300mm module, resulting in a closed smooth appearance
Panels are available as standard in steel (0.6mm) or aluminium (0.7mm)
Straight edges (300L) on the panelsides for a visually smooth ceiling
Beveled edges (300C) on the panelsides for a visually level ceiling
Panels can be supplied in any length up to 6000 mm (as standard) and are free spanning up to 2400mm length (300C) and 1800mm (300C)
Optimal acoustic control by using perforated panels with a non-woven textile membrane bonded to the inside face
Fire stable ceilings are possible with steel carriers, steel panels and steel edge profiles
Easily demountable panels allowing full access to services and equipment in plenum
Panels are lightweight yet strong, made from aluminium or steel which are both fully recyclable
Aluminium carriers in combination with aluminium panels can also be used for exterior application
Absence of dust retention and ease of cleaning make these panels ideal for any application where hygiene is important
Base Material: Luxalon® 300C/L panels are rollformed from 0.7 mm thick pre-painted stove enamelled aluminium strip or from 0.6 mm thick stove enamelled galvanised steel strip.
Coating: the tough and durable 2-layer polyester finish in a nominal thickness of 20 microns, is stove enamelled in a continuous coil-coating process ensuring uniform coating thickness and absolute adhesion.
Tolerances: as a member of the Technical Association of Industrial Metal Ceiling Manufacturers (TAIM-eV), Hunter Douglas complies with tolerance criteria as specified in chapter 4 of the TAIM Technical Manual on Metal Ceilings (THM) and the accompanying Quality Standards.
