Insulated Sandwich Wall System von Hunter Douglas

The HunterDouglas(r) Sandwich Wall PU panels are composed of two metal skins surrounding an insulating core of foam. Extremely flat panel surfaces in aluminium or steel are available in a variety of colours, surface finishes and shapes. Several joint systems, concealed fixing and glazing systems perfect the detailing and expand the architectural possibilities.




Characteristics

Polyurethane Foam core
Made to measure panels
Up to 12 meters in length
Standard widths but any panel module up to 1500 mm wide is available
Widths from 200 mm up to 1500 mm
Thicknesses include 35, 50, 60, 75 and 100 mm
Choice of skin materials: aluminium, steel
Superior panel flatness
Curved and cranked panels
Texture and formed skin shapes
Outstanding corrosion, scratch and UV resistant attractive finish
‘Total’ façade system including fully integrated windows, doors and louvres
Dry sealed system
Bi-modular joints, identical joint design at all four panel sides
Includes high performance weather tightness panels (CWCT/LPCB certified)
Horizontal and vertical installations
Unique, concealed mounting system
For new build and over-cladding projects
